| Model | HS-D046QW |
| Pick Up Device | 1/2.8” Mega Pixel CMOS |
| Resolution | 2048 x 1536 |
| S/N Ratio | More than 50dB |
| Zoom | 20X Optical zoom |
| Lens Type | f= 5.5mm(WIDE) ~ 110.0 mm (TELE), F1.6 ~ F3.5 |
| Min. Illumination | 0 Lux |
| Day & Night | Auto / Manual / Timing |
| Focus | Auto / Manual |
| Iris | Auto / Manual |
| White Balance | Auto / Manual |
| IR Distance | 100M |
| Preset | 360 Preset Positions (Max) |
| Pattern | 8 pattern tours, each one with 180s memory |
| Alarm | 1 alarm input and 1 output |
| Network Compression | H.265 / H.264 / MJPEG |
| Network Resolution | 2048 x 1536 |
| Network Frame Rate | 1~30 fps |
| Network Protocol | TCP/IP, UDP, DHCP, DDNS, NTP, RTSP, SMTP, FTP, PPPoE |
| Network Smart Alarm | Motion, Sensor |
| Network Storage | SD card local storage, network remote storage |
| Network Multi-stream | Yes |
| Interface Network | 10Base-T / 100Base-TX, RJ45 |
| Interface Audio | Mic inputx1, outputx1 |
| Interface Analog | CVBS x1 |
| Power Source | DC24V |
| Power Consumption | 16W (IR ON) |
| Dimension | Φ209 x 317mm |
| Operating Temperature | -10℃ ~ 50℃ |
| Weatherproof | IP66 |
