| Compression | H.265 / H.264 |
| Operating System | Embedded Linux |
| Network Input | 64 CH |
| Network Access Bandwidth | 320 Mbps |
| Network Access Format | 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P / 960H / D1 / CIF @25 / 30fps |
| Output | HDMI × 2 : HDMI 1: 4K / 2K / 1920 × 1080 / 1280 × 1024HDMI 2: 1920 × 1080 / 1280 × 1024 VGA × 1 : 1920 × 1080 / 1280 × 1024 |
| Network Input | 64 CH |
| 2-way Audio | RCA × 1 |
| Local Output | RCA × 1 |
| Record Stream | Dual / single stream recording |
| Mode | Manual / timer / motion / sensor |
| Simultaneous Playback | Max 16 CH |
| Search | IVS / Date & Time search / Event search |
| Function | Play / pause / FF / REW / digital zoom |
| Mode | Manual / sensor / motion / exception |
| Alarm Input ( IPC ) | 64 CH |
| Alarm Input ( NVR ) | 8 CH |
| Alarm Output ( IPC ) | 64 CH |
| Alarm Output ( NVR ) | 4 CH |
| Triggering | Record / snap / preset / e-mail / APP push message |
| Network Interface | RJ45 10 / 100 / 1000 Mbps × 2 |
| PoE Port | – |
| Serial Interface | RS485 x 2,(A,B for keyboard ;Z,Y for PTZ) |
| USB Interface | USB 2.0 × 2 ( one in the front panel and the other in the rear panel ) |
| Remote Controller | optional |
| Protocol | TCP / IP / PPPoE / DHCP / DNS / DDNS / UPnP / NTP / SMTP / RTSP / ONVIF |
| Network-Function | Support licensed CMS(100CH) / EMAP / IE |
| Web Client | Max 10 users online |
| Client Application | Display / Playback / Backup / DVR control / PTZ Control |
| SATA | 8 |
| e-SATA | 2 |
| Capacity | max 10TB per HDD |
| RAID | 0 / 1 / 5 / 6 / 10 |
| Local Backup | USB disk / USB mobile HDD ( limited ) |
| Network Backup | Yes |
| Operating System | iOS / Andriod |
| Power Supply | ATX 250W |
| Consumption | ≤ 15W ( without HDD ) |
| Dimensions | 435 × 456 × 99 ( W × D × H ) mm |
| Operating Temperature | -10 ～ 50 ℃ |
| Operating Humidity | 10% ～ 90% humidity |
