| Image Sensor | 1 / 2.7 ” CMOS |
| Image Size | 1920 × 1080 |
| Electronic Shutter | 1 / 25 s ~ 1 / 100000 s |
| Min. Illumination | 0.005 lux@F1.6,AGC ON; 0 lux with IR 0.0028 lux@F1.2,AGC ON; 0 lux with IR |
| Lens | EVF 2.8~12mm@F1.4 |
| Horizontal view Angle | 95.4°~35.5° |
| IR Distance | 30~50 m |
| WDR | Digital WDR |
| Day & Night | ICR auto switch |
| BLC | YES |
| HLC | YES |
| Defog | YES |
| Digital NR | 3D DNR |
| Angle Adjustment | Pan：0°~360°; Tilt：0°~90°; Rotation：0°~360° |
| Video Compression | H.265 / H.264 / MJPEG |
| H.264 Compression Standard | Baseline Profile / Main Profile / High Profile |
| Resolution | 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 |
| Main Stream (S1) | 60Hz : 1080P( 1 ~ 30fps ) / 720P( 1 ~ 30fps ) 50Hz : 1080P( 1 ~ 25fps ) / 720P( 1 ~ 25fps ) |
| Sub Stream (S2) | 60Hz : D1/CIF/480×240 (1~30fps) 50HZ: D1/CIF/480×240 (1~25fps) |
| Third Stream (S3) | – |
| Bit Rate | 128 Kbps ~ 4 Mbps |
| Bit Rate Type | VBR / CBR |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen,NR,etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Audio Compression | G711A / U |
| Two-way audio | – |
| Network | RJ45 |
| Video Output | – |
| Audio line in | – |
| Audio line out | – |
| Alarm Input | – |
| Alarm Output | – |
| SD card | Built-in micro SD card slot; up to 128GB |
| Network remote storage | Yes |
| Remote Monitoring | Web browsing,CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 3 users Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS |
| Interface Protocol | ONVIF, GB-T/28181-2011 |
| Smart Alarm | Motion detection; SD card full; SD card error |
| Intelligent Analytics | – |
| General function | Watermark, IP address filtering, video mask, heartbeat, password protection |
| PoE | Yes |
| Power Supply | DC12V / PoE |
| Power Consumption | < 5W |
| Operating Environment | – 30 °C ~ 60 °C (-22°F~140°F) Humidity: less than 95 % (non-condensing) |
| Dimensions | 217.7 × 80.5 × 80.5 |
| Weight | Approx. 640g |
| Installation | Ceiling mounting; wall mounting |
| Ingress Protection | IP66 |
