| Compression | H.265 / H.264 / MJPEG |
| Operating System | Embedded Linux |
| Network Input | 32 CH |
| Network Access Bandwidth | 256Mbps |
| Network Access Format | 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P @25 / 30fps |
| Output | HDMI × 2 : one of 4K × 2K / 1920 × 1080 / 1280 × 1024 the other of 1920 × 1080 / 1280 × 1024 VGA × 1 : 1920 × 1080 / 1280 × 1024 |
| Network Input | 32 CH |
| 2-way Audio | RCA × 1 |
| Local Output | RCA × 1 |
| Record Stream | Dual / single stream recording |
| Mode | Manual / timer / motion / sensor |
| Simultaneous Playback | Max 16 CH |
| Search | Face / IVS / Date & Time search / Event search |
| Function | Play / pause / FF / REW / digital zoom |
| Mode | Manual / sensor / motion / exception |
| Alarm Input ( IPC ) | 32 CH |
| Alarm Input ( NVR ) | 8 CH |
| Alarm Output ( IPC ) | 32 CH |
| Alarm Output ( NVR ) | 4 CH |
| Triggering | Record / snap / preset / e-mail / APP push message |
| Network Interface | RJ45 1000 Mbps × 1 |
| PoE Port | – |
| Serial Interface | RS485 x 2 (A,B for keyboard ; Z,Y for PTZ) |
| Statistic Mode of Face Information | USB 2.0 × 1 ( front panel ) USB 3.0 × 1 ( rear panel ) |
| Remote Controller | optional |
| Protocol | TCP / IP / PPPoE / DHCP / DNS / DDNS / UPnP / NTP / SMTP / RTSP / ONVIF |
| Network-Function | Support licensed CMS(100CH) / EMAP / IE |
| Web Client | Multi-user online simultaneously |
| Client Application | Display / Playback / Backup / DVR control / PTZ Control |
| SATA | 8 |
| e-SATA | 2 |
| Capacity | max 10TB per HDD |
| RAID | 0 / 1 / 5 / 6 / 10 |
| Local Backup | USB disk / USB mobile HDD ( limited ) |
| Network Backup | Yes |
| Operating System | iOS / Andriod |
| Channel | 32 CH |
| Face Picture Database | 16 libraries 10000 Face Pictures |
| Computing Capability | 240 pictures / minute |
| Face Picture Search | Search by picture is supported |
| Database Management | Add, modify, delete and search face pictures |
| Face Picture Adding | Add face pictures through APP,WEB and local PC |
| External face picture enrollment | Resolution：64 × 64～1920 × 1080 Size：less than 200KB Format：jpg |
| Face Picture Comparison | Support allow list and block list alarm |
| Face Trace | Yes |
| Map of Face Trace | Reolution：600 × 300～3840 × 2160 Size：within 200KB Format：jpg |
| Statistic Graph of Face Information | Bar graph, pie chart |
| Statistic Mode of Face Information | Statistics by day, week, month,quarter as well as customized time period |
| Network Interface | RJ45 10 / 100 / 1000 Mbps × 2 |
| PoE Port | – |
| Serial Interface | RS485 x 2 (A,B for keyboard ;Z,Y for PTZ) |
| USB Interface | USB 2.0 × 2 ( one in the front panel and the other in the rear panel ) |
| Remote Controller | Optional |
| Protocol | TCP / IP / PPPoE / DHCP / DNS / DDNS / UPnP / NTP / SMTP / RTSP / ONVIF |
| Network-Function | Support licensed CMS(100CH) / EMAP / IE |
| Web Client | Max 10 users online |
| Client Application | Display / Playback / Backup / DVR control / PTZ Control |
| Power Supply | ATX ( AC 110V / 240V ) |
| Consumption | ≤ 15W ( without HDD ) |
| Dimensions | 435 × 456 × 99 ( W × D × H ) mm |
| Operating Temperature | -10 ～ 50 ℃ |
| Operating Humidity | 10% ～ 90% humidity |
