| Image Sensor | 1 / 2.9 ” CMOS |
| Image Size | 1920 × 1080 |
| Electronic Shutter | 1 / 25 s ~ 1 / 100000 s |
| Min. Illumination | 0.0035 lux@F1.2,AGC ON; 0 lux with IR 0.013 lux@F2.0,AGC ON; 0 lux with IR |
| Lens | VF 2.8 ~ 12 mm @F1.4 |
| Horizontal view Angle | 88°~34.8° |
| IR Distance | 30~50 m |
| Day & Night | ICR auto switch |
| WDR | YES |
| BLC | YES |
| HLC | YES |
| Digital Defog | YES |
| Digital DNR | 3 DNR |
| Video Compression | H.265 / H.264 / MJPEG |
| H.265 Compression Standard | Main Profile @Leve4.1 High Tier |
| Resolution | 1080P ( 1920 × 1080 ), 720P ( 1280 × 720 ), D1, CIF, 480 × 240 |
| Main Stream (S1) | 1080P / 720P @30fps |
| Sub Stream (S2) | D1 / CIF / 480 × 240 @30fps |
| Third Stream (S3) | – |
| Bit Rate | 64 Kbps ~ 6 Mbps |
| Bit Rate Type | VBR / CBR |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast,Wide Dynamic, Sharpen,NR,etc. adjustable through client software or web browser |
| ROI | Each ROI to be configured separately |
| Audio Compression | G711A / U |
| Two-way audio | – |
| Network | 1 x RJ45 |
| Video Output | – |
| Audio | 1CH built-in MIC |
| SD card | Built-in micro SD card slot; up to 128GB |
| Network remote storage | Yes |
| Hardware Reset | Yes |
| Remote Monitoring | Web browsing,CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 3 users Support multi-stream real time transmission |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, 802.1x, UPnP, HTTPs, HTTP, QoS |
| Interface Protocol | ONVIF |
| Smart Alarm | Motion detection, SD card full, SD card error |
| Intelligent Analytics | Video blur detection, Line Crossing, Intrusion |
| General function | Watermark, IP address filtering, video mask, heartbeat, illegal login lock |
| PoE | Yes , IEEE802.3 af |
| Power Supply | DC12V / PoE |
| Power Consumption | < 8W |
| Operating Environment | – 30 °C ~ 60 °C (-22°F~140°F) Humidity: less than 95 % (non-condensing) |
| Dimensions | Φ 111.5 × 99.6 |
| Weight | Approx. 640g |
| Installation | Ceiling mounting (wall mounting available with the junction box and bracket) |
| Ingress Protection | IP67 |
